ADV100 • Quick installation guide - Specifications and connection 49
ENUM type parameter: displays the numeric value corresponding to the current selection.
Command: in the case of an error in the command, indicates that ESC must be pressed to terminate the com-
mand.
Messages and error conditions:
Param read only attempt to modify a read-only parameter
Password active the parameter protection password is active
Drive enabled attempt to modify a non-modiable parameter with the drive enabled
Input value too high the value entered too high
Input value too low the value entered too low
Out of range attempt to insert a value outside the min. and max. limits
8.2.3 Scanning of the parameters
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 REFERENCES
01 MONITOR
01/20 PAR: 250
Output current
0.0 A
0%
01 MONITOR
20/20 PAR: 1400
Digital outpu
t
X mon
00000000010001
01 MONITOR
02/20 PAR: 252
Output voltage
0 v
0%
8.2.4 List of the last parameters modied
Pressing the CUST key, a list containing the last 10 parameters modied is accessed. One parameter is displayed at a
time and the list can be scrolled using the ▲ and ▼ keys.
To exit this list, press the ► key.
8.2.5 "FIND" function
Pressing the FIND key activates the function that makes it possible to access any parameter simply by entering the
parameter software number (PAR).
When the parameter reached by the "FIND" command is displayed, it is possible to navigate all the parameters forming
part of the same group using the ▲ and ▼ keys. Pressing the ► key returns to the “FIND” function.
To exit, press the ► key.
8.3 Parameter modication
To enter parameter modication mode, press the E key when the parameter to be modied is displayed.
To save the value of the parameter, following modication, press the E key again.
Note! To save permanently, see paragraph 8.4.
To exit modication mode without saving the value, press the ESC key.
The operations to be carried out to modify the value depend on the type of the parameter, as described below.
Note! For further information about the type of parameters displayed, see paragraph 8.2.2.
Numeric parameters
16 MOTOR DATA
17 ENCODER CONFIG
18 SPEED REG GAINS
19 REGULATOR PARAM
20 TORQUE CONFIG
16
MOTOR DATA
01/26 PAR: 2000
Rated voltage
400 V
Def: 400
E
16
MOTOR DATA
01/26 PAR: 2000
Rated voltage
000000400 v
Def: 400
When E is pressed to access modication mode, the cursor is activated on the digit corresponding to the unit.
Using the ◄ and ► keys, the cursor can be moved to all the digits, including trailing zeros that are normally not
displayed.
With the ▲ and ▼ keys, the digit under the cursor is increased or decreased.
Press E to conrm the modication or ESC to cancel.
