ADV100 • Quick installation guide - Specifications and connection 73
11 - Parameters list
11.1 Legend
Menu IPA Description EU Type Type FB Def Min Max Acc Mod
22 - FUNCTIONS (Level 1 menu)
22.1 - FUNCTIONS/INERTIA COMP (Level 2 menu)
22.1.1 3100 Inertia comp kgm2 FLOAT 0.0 0.0 100.0 ERWS F�S
22.1.2 3102 Inertia comp filter ms UINT16 30 1 100 ERW F�S
22.1.3 3104 Inertia comp mon perc FLOAT 16/32BIT 0.0 0.0 0.0 ER F�S
22.2 - FUNCTIONS/DC BRAKING
22.2.1 3150 DC braking cmd src LINK 16BIT 6000 0 16384 ERW FVS
L�DIGSEL2 (Selectionlist[*])
Indexing of the menu and parameter
Parameter identifier
Parameter description
UM: unit of measure
Type of parameter
BIT Boolean, from modbus seen as 16 bits
ENUM Selection list, from modbus seen as 16 bits
FLOAT Real, from modbus seen as 32 bits
FBM2SIPA 16-bit unsigned integer. Only PAR of existing parameters accepted.
FBS2MIPA 16-bit unsigned integer. Only PAR of existing parameters accepted.
INT16 Integer with sign 16 bits, from modbus seen as 16 bits
INT32 Integer with sign 32 bits, from modbus seen as 32 bits
ILINK Selection list, from modbus seen as 16 bits
LINK Selection list, from modbus seen as 16 bits
UINT16 Integer without sign 16 bits , from modbus seen as 16 bits
UINT32 Integer without sign 32 bits, from modbus seen as 32 bits
Format of data exchanged on Fieldbus (16BIT, 32BIT)
Default value
CALCF Value calculated as a number with floating point
CALCI Value calculated as a whole number
SIZE Value depending on the size of the drive
Minimum value
Maximum value
Accessibility :
E Expert
R Read
S Size (set value depending on the size of the device)
W Write
Z parameters that can be modified ONLY with the drive disabled
Available in regulation mode:
V = V/f Control
S = Vect Flux OL
F = Vect Flux CL
[*]
Selection lists:
The “... src” format parameters are linked to a selection list.
The source of the signal that will control the parameter can be selected from the list indicated.
The lists are indicated in paragraph 11.3 of this manual.
