16 ADV100 • Quick installation guide - Specifications and connection
Size In [A] Overload 150 %
K1 [%] K2 [Hz]
1040 9,5
100 3
1055 13
100 3
2075 16,5
100 3
2110 23
100 3
3150 31
100 5
3185 38
100 5
3220 46
100 3
4300 62
100 3
4370 75
100 3
4450 87
100 3
5550 105
100 3
5750 150
100 5
5900 180
100 5
4.5.2 Switching frequency
1) PAR 568 Switching freq mode = [0] Constant
PAR 562 Switching frequency = see chapter 4.5, default column "Switching frequency".
It is possible to set a xed switching frequency (from 4 to 12 kHz depending on the size and with derating where ap-
plicable).
2) PAR 568 Switching freq mode = [1] Variable
PAR 562 Switching frequency = no effect
The switching frequency is variable between two levels (hswf and lswf) which are dened by the heatsink temperature
and output frequency:
hswf = Default switching frequency
lswf = Switching frequency when Fout or T reach the values showed in table
Size fSw Switching frequency F out T
Higher [kHz] Lower [kHz] [Hz] [°C]
1040 8
4 3 70
1055 8
4 3 75
2075 8
4 3 70
2110 8
4 3 70
3150 8
4 3 70
3185 8
4 3 75
3220 8
4 3 75
4300 8
4 3 65
4370 8
4 3 70
4450 8
4 3 75
5550 8
4 3 70
5750 8
4 5 65
5900 8
4 5 65
