ADV100 • Quick installation guide - Specifications and connection 33
7.1.10 Parallel connection on the AC (Input) and DC (Intermediate Circuit) side of several inverters
M1
3
M2
3
M6
3
F11
F21
F61
L1
L2
L3
U
V
W
C
D
INVERTER 1
L1
L2
L3
U
V
W
C
D
INVERTER 2
BR1
F12
F22
F62
L1
L2
L3
U
V
W
C
D
INVERTER 6
BR
CR
C
D
B y-...U
(MASTER)
7 8 9 10
R
BR
F7
R
BR
L1
L2
L3
K1
M..
3
F..
L1
L2
L3
U
V
W
C
D
INVERTER ..
F..
(*)
BR2
- The inverters used have to be all the same size.
- The mains power supply has to be simultaneous for all inverters, i.e. a single switch /line contactor has to be used.
- Such connection is suitable for a maximum of 6 inverters.
- If necessary dissipate braking energy; a single internal braking unit (with external resistor) has to be used or one (or several) external braking unit.
- Fast fuses (F12...F62) have to be tted on the dc-link side ( C and D terminals) of each inverters (see chapter 5.1.2).
(*) Do not connect if external braking units BUy.. is used.
(*) Pas raccorder si l’unité de freinage extérieure BUy... est utilisée
Caution
