8.1.2 Meaning of LEDs
LEDs Colore Significato dei Led
T+ Yellow The LED is lit, when the drive operates with a positive torque
T- Yellow The LED is lit, when the drive operates with a negative torque
EN Green The LED is lit during IGBT modulation (drive operating)
ILIM Red When this LED is lit the drive has reached a current limit condition. During normal functioning, this LED is off.
N=0 Yellow The LED is lit when motor speed is 0.
AL Red The LED is lit when the drive signals that an alarm has been triggered
8.2 Navigation
8.2.1 Scanning of the rst and second level menus
1st level
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 REFERENCES

23 ALARM LOG
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG

01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 REFERENCES
1st level 2nd level
22 FUNCTIONS
23 COMMUNICATION
24 ALARM CONFIG
25 ALARM LOG
01 MONITOR

22.1 INERTIA COMP
22.2 DC BRAKING
22.3 MOTOR OVERLOAD
22.4 BRES OVERLOAD
22.5 SPEED CAPTURE
Note! This example is only visible in Expert mode..
8.2.2 Display of a parameter
j
16 MOTOR DATA
k
01/26 PAR: 2000

l
Rated voltage
400 V
o
m
Def: 400
(1) Reference to the menu where the parameter is to be found (in this case menu 16 - MOTOR DATA)
(2) Position of the parameter in the menu structure (01)
(3) Description of the parameter (Rated voltage)
(4) Depends on the type of parameter:
• Numeric parameter: displays the numeric value of the parameter, in the format required, and unit of measurement.
• Binary selection: the parameter may assume only 2 states, indicated as On - Off or 0 - 1.
• LINK type parameter: displays the description of the parameter set from the selection list.
• ENUM type parameter: displays the description of the selection
• Command: displays the method of execution of the command
(5) Parameter number
(6) In this position, the following may be displayed:
• Numeric parameter: displays the default, minimum and maximum values of the parameter. These values are dis-
played in sequence pressing the ► key.
• LINK type parameter: displays the number (PAR) of the parameter set.
