26 ADV100 • Quick installation guide - Specifications and connection
Recommended screws for fastening
Size 1 (ADV...-1...) 4 x M5 x 12 mm screws + Grover (spring-lock) washer + at washer
Size 2 (ADV...-2...) 4 x M5 x 12 mm screws + Grover (spring-lock) washer + at washer
Size 3 (ADV...-3...) 4 x M5 x 12 mm screws + Grover (spring-lock) washer + at washer
Size 4 (ADV...-4...) 4 x M6 x 16 mm screws + Grover (spring-lock) washer + at washer
Size 5 (ADV...-5...) 5 x M6 x 16 mm screws + Grover (spring-lock) washer + at washer
Note! Other dimensions see chapter 4.8 Weights and dimensions.
