88 ADV100 • Quick installation guide - Specifications and connection
Menu IPA Description EU Type Type FB Def Min Max Acc Mod
8 Eu float
9 Par16
10 Par32
23.4.3 4184 Dig Fieldbus S->M1 INT3232 BIT 0 0 0 ERW FVS
23.4.4 4186 Fieldbus S->M1 mul float 1.0 1.0 1000.0 ERW FVS
23.4.5 4190 Fieldbus S->M2 ipa FBS2MIPA 0 0 20000 RW FVS
23.4.6 4192 Fieldbus S->M2 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.4.7 4194 Dig Fieldbus S->M2 INT32 32 BIT 0 0 0 ERW FVS
23.4.8 4196 Fieldbus S->M2 mul float 1.0 1.0 1000.0 ERW FVS
23.4.9 4200 Fieldbus S->M3 ipa FBS2MIPA 0 0 20000 RW FVS
23.4.10 4202 Fieldbus S->M3 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.4.11 4204 Dig Fieldbus S->M3 INT32 32 BIT 0 0 0 ERW FVS
23.4.12 4206 Fieldbus S->M3 mul float 1.0 1.0 1000.0 ERW FVS
23.4.13 4210 Fieldbus S->M4 ipa FBS2MIPA 0 0 20000 RW FVS
23.4.14 4212 Fieldbus S->M4 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.4.15 4214 Dig Fieldbus S->M4 INT32 32 BIT 0 0 0 ERW FVS
23.4.16 4216 Fieldbus S->M4 mul float 1.0 1.0 1000.0 ERW FVS
23.4.17 4220 Fieldbus S->M5 ipa FBS2MIPA 0 0 20000 RW FVS
23.4.18 4222 Fieldbus S->M5 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.4.19 4224 Dig Fieldbus S->M5 INT32 32 BIT 0 0 0 ERW FVS
23.4.20 4226 Fieldbus S->M5 mul float 1.0 1.0 1000.0 ERW FVS
23.4.21 4230 Fieldbus S->M6 ipa FBS2MIPA 0 0 20000 RW FVS
23.4.22 4232 Fieldbus S->M6 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
