90 ADV100 • Quick installation guide - Specifications and connection
Menu IPA Description EU Type Type FB Def Min Max Acc Mod
10 Par32
23.4.43 4284 Dig Fieldbus S->M11 INT32 32 BIT 0 0 0 ERW FVS
23.4.44 4286 Fieldbus S->M11 mul float 1.0 1.0 1000.0 ERW FVS
23.4.45 4290 Fieldbus S->M12 ipa FBS2MIPA 0 0 20000 RW FVS
23.4.46 4292 Fieldbus S->M12 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.4.47 4294 Dig Fieldbus S->M12 INT32 32 BIT 0 0 0 ERW FVS
23.4.48 4296 Fieldbus S->M12 mul float 1.0 1.0 1000.0 ERW FVS
23.4.49 4300 Fieldbus S->M13 ipa FBS2MIPA 0 0 20000 RW FVS
23.4.50 4302 Fieldbus S->M13 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.4.51 4304 Dig Fieldbus S->M13 INT32 32 BIT 0 0 0 ERW FVS
23.4.52 4306 Fieldbus S->M13 mulo float 1.0 1.0 1000.0 ERW FVS
23.4.53 4310 Fieldbus S->M14 ipa FBS2MIPA 0 0 20000 RW FVS
23.4.54 4312 Fieldbus S->M14 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.4.55 4314 Dig Fieldbus S->M14 INT32 32 BIT 0 0 0 ERW FVS
23.4.56 4316 Fieldbus S->M14 mul float 1.0 1.0 1000.0 ERW FVS
23.4.57 4320 Fieldbus S->M15 ipa FBS2MIPA 0 0 20000 RW FVS
23.4.58 4322 Fieldbus S->M15 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
23.4.59 4324 Dig Fieldbus S->M15 INT32 32 BIT 0 0 0 ERW FVS
23.4.60 4326 Fieldbus S->M15 mul float 1.0 1.0 1000.0 ERW FVS
23.4.61 4330 Fieldbus S->M16 ipa FBS2MIPA 0 0 20000 RW FVS
23.4.62 4332 Fieldbus S->M16 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count16
2 Count32
3 Fill16
4 Fill32
5 Mdplc16
6 Mdplc32
7 EU
8 Eu float
9 Par16
10 Par32
