98 ADV100 • Quick installation guide - Specifications and connection
PAR Description Menu PAR Description Menu PAR Description Menu
4464 Bit5 decomp mon 23.6.8
4466 Bit6 decomp mon 23.6.9
4468 Bit7 decomp mon 23.6.10
4470 Bit8 decomp mon 23.6.11
4472 Bit9 decomp mon 23.6.12
4474 Bit10 decomp mon 23.6.13
4476 Bit11 decomp mon 23.6.14
4478 Bit12 decomp mon 23.6.15
4480 Bit13 decomp mon 23.6.16
4482 Bit14 decomp mon 23.6.17
4484 Bit15 decomp mon 23.6.18
3700 Pad 1 22.7.1
3702 Pad 2 22.7.2
3704 Pad 3 22.7.3
3706 Pad 4 22.7.4
3708 Pad 5 22.7.5
3710 Pad 6 22.7.6
3712 Pad 7 22.7.7
3714 Pad 8 22.7.8
3716 Pad 9 22.7.9
3718 Pad 10 22.7.10
3720 Pad 11 22.7.11
3722 Pad 12 22.7.12
3724 Pad 13 22.7.13
3726 Pad 14 22.7.14
3728 Pad 15 22.7.15
3730 Pad 16 22.7.16
1630 Analog inp1X<thr 0.0 (*)
1680 Analog inp2X<thr 0.0 (*)
1048 FR start mon 11.20
1050 FR reverse mon 11.21
3480 Vdc ctrl ramp freeze 0.0 (*)
3342 Energysave out run 0.0 (*)
L_DIGSEL3
XXXX (2)
6000 Null 0.0 (*)
6002 One 0.0 (*)
1110 Digital input E mon 0.0 (*)
1210 Digital input 1X mon 0.0 (*)
1212 Digital input 2X mon 0.0 (*)
1214 Digital input 3X mon 0.0 (*)
1216 Digital input 4X mon 0.0 (*)
1218 Digital input 5X mon 0.0 (*)
1220 Digital input 6X mon 0.0 (*)
1222 Digital input 7X mon 0.0 (*)
1224 Digital input 8X mon 0.0 (*)
1062 Drive OK 0.0 (*)
1064 Drive ready 0.0 (*)
934 Ref is 0 0.0 (*)
936 Ref is 0 delay 0.0 (*)
944 Speed is 0 0.0 (*)
946 Speed is 0 delay 0.0 (*)
956 Speed thr 1_2 mon 0.0 (*)
966 Set speed 0.0 (*)
976 Speed thr 3 mon 0.0 (*)
986 Current thr mon 0.0 (*)
1066 Enable state mon 1.16
1068 Start state mon 1.17
1070 FastStop state mon 1.18
1024 Enable cmd mon 11.13
1026 Start cmd mon 11.14
1028 FastStop cmd mon 11.15
4708 Alm dig out mon 1 0.0 (*)
4710 Alm dig out mon 2 0.0 (*)
4712 Alm dig out mon 3 0.0 (*)
4714 Alm dig out mon 4 0.0 (*)
1630 Analog inp1X<thr 0.0 (*)
1680 Analog inp2X<thr 0.0 (*)
362 Drive overload trip 0.0 (*)
3214 Motor overload trip 0.0 (*)
3262 Bres overload trip 0.0 (*)
366 Drive overload 80% 0.0 (*)
1048 FR start mon 11.20
1050 FR reverse mon 11.21
4454 Bit0 decomp mon 23.6.3
4456 Bit1 decomp mon 23.6.4
4458 Bit2 decomp mon 23.6.5
4460 Bit3 decomp mon 23.6.6
4462 Bit4 decomp mon 23.6.7
4464 Bit5 decomp mon 23.6.8
4466 Bit6 decomp mon 23.6.9
4468 Bit7 decomp mon 23.6.10
4470 Bit8 decomp mon 23.6.11
4472 Bit9 decomp mon 23.6.12
4474 Bit10 decomp mon 23.6.13
4476 Bit11 decomp mon 23.6.14
4478 Bit12 decomp mon 23.6.15
4480 Bit13 decomp mon 23.6.16
4482 Bit14 decomp mon 23.6.17
4484 Bit15 decomp mon 23.6.18
3700 Pad 1 22.7.1
3702 Pad 2 22.7.2
3704 Pad 3 22.7.3
3706 Pad 4 22.7.4
3708 Pad 5 22.7.5
3710 Pad 6 22.7.6
3712 Pad 7 22.7.7
3714 Pad 8 22.7.8
3716 Pad 9 22.7.9
3718 Pad 10 22.7.10
3720 Pad 11 22.7.11
3722 Pad 12 22.7.12
3724 Pad 13 22.7.13
3726 Pad 14 22.7.14
3728 Pad 15 22.7.15
3730 Pad 16 22.7.16
6004 Speed limit state 0.0 (*)
6006 Current limit state 0.0 (*)
764 Ramp acc state 0.0 (*)
766 Ramp dec state 0.0 (*)
4780 Alarm PLC 0.0 (*)
(2) the XXXX parameter changes according to the
src parameter used:
1014 Local/remote src
(2) = Dig local/remote 11.7
L_FBS2M
XXXX (3)
6000 Null 0.0 (*)
6002 One 0.0 (*)
626 Ramp ref out mon 0.0 (*)
628 Ramp setpoint 1.4
760 Ramp out mon 0.0 (*)
664 Speed setpoint 1.5
260 Motor speed 1.6
262 Motor speed nolter 0.0 (*)
2150 Encoder 1 speed 17.11
250 Output current 1.1
252 Output voltage 1.2
254 Output frequency 1.3
280 Torque current ref 1.9
282 Magnet current ref 1.10
284 Torque current 1.11
286 Magnet current 1.12
2360 Torque lim Pos Inuse 20.6
2362 Torque lim Neg Inuse 20.7
2386 Torque ref 20.11
2388 Torque ref nolter 0.0 (*)
270 DC link voltage 1.7
2162 Encoder 1 position 17.12
2154 E1 Virtual position 27.3.2
2156 E1 Revolutions 27.3.3
852 Multi ref out mon 7.24
870 Mpot setpoint 8.1
894 Mpot output mon 8.13
920 Jog output mon 9.6
3104 Inertia comp mon 22.1.3
1600 Analog input 1X mon 14.1
1650 Analog input 2X mon 14.16
368 Drive overload accum 1.14
3212 Motor overload accum 1.13
3260 Bres overload accum 1.15
272 Heatsink temperature 1.8
1060 Sequencer status 0.0 (*)
4432 Word comp mon 23.5.17
3446 Powerloss nextratio 0.0 (*)
4372 DS402 status word 0.0 (*)
4024 Fieldbus M->S1 mon 23.3.3
4034 Fieldbus M->S2 mon 23.3.7
4044 Fieldbus M->S3 mon 23.3.11
4054 Fieldbus M->S4 mon 23.3.15
4064 Fieldbus M->S5 mon 23.3.19
4074 Fieldbus M->S6 mon 23.3.23
4084 Fieldbus M->S7 mon 23.3.27
4094 Fieldbus M->S8 mon 23.3.31
4104 Fieldbus M->S9 mon 23.3.35
4114 Fieldbus M->S10 mon 23.3.39
4124 Fieldbus M->S11 mon 23.3.43
4134 Fieldbus M->S12 mon 23.3.47
4144 Fieldbus M->S13 mon 23.3.51
4154 Fieldbus M->S14 mon 23.3.55
4164 Fieldbus M->S15 mon 23.3.59
4174 Fieldbus M->S16 mon 23.3.63
3700 Pad 1 22.7.1
3702 Pad 2 22.7.2
3704 Pad 3 22.7.3
3706 Pad 4 22.7.4
3708 Pad 5 22.7.5
3710 Pad 6 22.7.6
3712 Pad 7 22.7.7
3714 Pad 8 22.7.8
3716 Pad 9 22.7.9
3718 Pad 10 22.7.10
3720 Pad 11 22.7.11
3722 Pad 12 22.7.12
3724 Pad 13 22.7.13
3726 Pad 14 22.7.14
3728 Pad 15 22.7.15
3730 Pad 16 22.7.16
4770 First alarm 0.0 (*)
4840 Alarm lo state 0.0 (*)
4842 Alarm hi state 0.0 (*)
1200 Digital input X mon 1.19
5008 Test gen out 27.1.5
(3) the XXXX parameter changes according to the
src parameter used:
4340 DS402 cw src
(3) = 4024 Fieldbus M->S1 mon 23.3.3
L_LIM
6000 Null 0.0 (*)
2380 Dig torque ref 1 20.8
1600 Analog input 1X mon 14.1
1650 Analog input 2X mon 14.16
4024 Fieldbus M->S1 mon 23.3.3
4034 Fieldbus M->S2 mon 23.3.7
4044 Fieldbus M->S3 mon 23.3.11
4054 Fieldbus M->S4 mon 23.3.15
4064 Fieldbus M->S5 mon 23.3.19
4074 Fieldbus M->S6 mon 23.3.23
4084 Fieldbus M->S7 mon 23.3.27
4094 Fieldbus M->S8 mon 23.3.31
4104 Fieldbus M->S9 mon 23.3.35
4114 Fieldbus M->S10 mon 23.3.39
4124 Fieldbus M->S11 mon 23.3.43
4134 Fieldbus M->S12 mon 23.3.47
4144 Fieldbus M->S13 mon 23.3.51
4154 Fieldbus M->S14 mon 23.3.55
4164 Fieldbus M->S15 mon 23.3.59
4174 Fieldbus M->S16 mon 23.3.63
3700 Pad 1 22.7.1
3702 Pad 2 22.7.2
3704 Pad 3 22.7.3
3706 Pad 4 22.7.4
3708 Pad 5 22.7.5
3710 Pad 6 22.7.6
3712 Pad 7 22.7.7
3714 Pad 8 22.7.8
3716 Pad 9 22.7.9
3718 Pad 10 22.7.10
3720 Pad 11 22.7.11
3722 Pad 12 22.7.12
3724 Pad 13 22.7.13
3726 Pad 14 22.7.14
3728 Pad 15 22.7.15
3730 Pad 16 22.7.16
5008 Test gen out 27.1.5
L_MLTREF
XXXX (4)
852 Multi ref out mon 7.24
894 Mpot output mon 8.13
2150 Encoder 1 speed 17.11
