T curr lim type Thisparametersdeterminesthebehaviourofthedriveincurrentlimitcondition.
 Tlim+/- TheactivepositivetorquelimitisTcurrentlimandtheactive
negativetorquelimitisTcurrentlim-.
 Tlimmot/gen Withthisselection3conditionsarepossible:
  1-Ifthemotorspeed>+1%ofMotor max speedtheactive
positivetorquelimitisT current lim+andtheactivenegative
torquelimitisTcurrentlim-.
  2-Ifthemotorspeed<-1%ofMotor max speedtheactive
positivetorquelimitisT current lim-andtheactivenegative
torquelimitisTcurrentlim+.
  3-If-1%ofMotor max speed<motorspeed<+1%of
Motor max speedtheactivepositivetorquelimitisT current
lim+andtheactivenegativetorquelimitisTcurrentlim+.
speed
torque
T current lim +
T current lim -Tcurrent lim -
T current lim +
speed
torque
T current lim +
T current lim -
T current lim -
T current lim +
+1% of Motor max speed-1% of Motor max speed
T current lim SymmetricalcurrentlimitforbothcurrentdirectionsforTPD32-EV...4Bconverters.
DenedasapercentageoftheFull load currparameter.Themaximumvaluedepends
ontheEnable overloadparameter.
Enable overload Disabled T current limit  100%max
Enable overload  Enabled T current limit  200%max
 IftheTcurrentlimitparameterischanged,theParameterT current lim +andT current
lim -parametersaresettothesamevalue.Ifboththeseparametersaresubsequently
changed,thelastchangeisvalid.
T current lim + Settingofthedrivecurrentlimitforthepositivecurrentdirection(clockwisedriveand
counter-clockwisebrake).EnteredasapercentageoftheFull load curr value.The
maximumvaluedependsonthevalueofthe Enable overload parameter.
Enable overload  Disabled T current lim+ 100%max
Enable overload Enabled T current lim+ 200%max
T current lim - Settingofthedrivecurrentlimitforthenegativecurrentdirection(counterclockwise
driveandclockwisebrake).EnteredasapercentageoftheFull load curr parameter.
ThemaximumvaluedependsonthevalueoftheEnable overloadparameter.This
parameterisnotactivefortheTPD32-EV...4Bconverters.
Enable overload Disabled T current lim-  100%max
Enable overload Enabled T current lim-  200%max
Curr limit state Statusmessage,indicatingwhetherthedriveisworkingwiththesetcurrentlimitornot.
 High Driveworkingatthecurrentlimit.“I
Limit
”LEDlightsup.
 Low Drivenotworkingatthecurrentlimit.
