gefran TPD32-EV-500 series - Configuration of the Speed Feedback Circuit

—————— TPD32-EV ——————
188
6.11.5 Configuration of the speed feedback circuit
CONFIGURATION
Speed fbk
[162] Motormaxspeed[rpm]
[414] Speedfbksel
[457] Enablefbkcontr
[458] Enablefbkbypas
[456] Fluxweakspeed[%]
[455] Speedfbkerror[%]
[562] Tachoscale
[563] Speedoffset
[416] Encoder1pulses
[169] Encoder2pulses
[649] Refreshenc1
[652] Refreshenc2
[911] Enableindstore
Parameter description No.
Value
Standard
Conguration
min max
Factory
American
Factory
Standard
Motor max speed [rpm]
162 0 6553 1500 1500
-
Speed fbk sel
Encoder1(0)
Encoder2(1)
Tacho(2)
Armature(3)
414 0 3 1 1
-
Encoder 1 state
EncoderFault(0)
Encoderok(1)
648 0 1
-
Enable fbk contr
Enabled(1)
Disabled(0)
457 0 1 Enabled
(1)
Enabled
(1)
-
Enable fbk bypas
Enabled(1)
Disabled(0)
458 0 1 0 0
-
Flux weak speed [%]
456 0 100 100 100
-
Speed fbk error [%]
455 0 100 22 22
-
Tacho scale
562 0.90 3.00 1.00 1.00
-
Speed offset
563 -20.00 +20.00 0.00 0.00
-
Encoder 1 pulses
416 600 9999 1024 1024
-
Encoder 2 pulses
169 150 9999 1000 1000
-
Refresh enc 1
Enabled(1)
Disabled(0)
649 0 1 Disabled(0) Disabled(0)
-
Encoder 2 state
EncoderFault(0)
Encoderok(1)
651 0 1
-
Refresh enc 2
Enabled(1)
Disabled(0)
652 0 1 Disabled(0) Disabled(0)
-
Enable ind store
Enabled(1)
Disabled(0)
911 0 1 Disabled(0) Disabled(0)
-
Ind store ctrl
912 0 65535 0 0
-
Index storing
913 0 +232-1 0 0
-
note! TheencoderorthetachometerarenecessaryfortheregulationmodeFluxregmode“Voltage
control”and“Externalcontrol”.Thefeaturesoftheelectricaldataoftheencoderandthe
tachometeraredenedinsections2.7.2,“Encoder/Tachometer”,and2.4.5,“Accuracy”.
