486
1400 1600/0,4 OFF ON 1,750000 0,349714 146 10010010 000010010010
1500 1600/0,4 OFF ON 1,875000 0,326400 157 10011100 000010011100
1700 1600/0,4 OFF ON 2,125000 0,288000 178 10110001 000010110001
1800 1600/0,4 OFF ON 2,250000 0,272000 188 10111100 000010111100
2000 2400/0,5 OFF ON 2,083333 0,293760 174 10101110 000010101110
2400 2400/0,5 OFF ON 2,500000 0,244800 209 11010001 000011010001
2700 2400/0,5 OFF ON 2,812500 0,217600 235 11101011 000011101011
2900 4000/0,5 OFF ON 1,812500 0,337655 152 10010111 000010010111
3300 4000/0,5 OFF ON 2,062500 0,296727 173 10101100 000010101100
PositionontheFIRXP-XXcard:see"Figure11.3.5:FIR4/5P-XXpower/drivercard"onpage473.
A1.6.4 Using the control unit as a replacement part
TheTPD32-EV-CU-…canalsobeusedas:
• areplacementpartforTPD32-…“externalbridge”controlunitspreviousseries,
• areplacementpartforTPD32-EV-...-Eseries.
HavingidentiedtheappropriateTPD32-EV-CU-…accordingtothemainsvoltage,eldratedcurrent,typeof
pulsetransformer(forallstandarddrivesupto3300Athecorrecttypeis“THY1”),congurethedip-switches
asshownintables"Table11.3.6:Selectionofdip-switches“S3-XX”and“S4-XX”forFIR4/5P-XXcards."on
page474and"TableA.1.6.3.1:Calculationofthecongurationofdip-switchesSW3-1toSW4-8forstandard
TPD32-EV-..driveswithexternalbridge"onpage485above.
InserttwoEAM2760andEAM2761adaptercablesbetweenthetwoKPandKPT11cablesconnectedtothe
existingpowerbridgeandthenewTPD32-EV-CU-….ConnecttheseadaptercablestoconnectorsKP,KPT31
andKPT11onthenewcontrolunitasshown"Figure9.4.3-B:ESE5799(2/3)-TPD32-EV-CU-"onpage423.
A1.7 DC Converter size management
ThisfunctionmakestheCUuniversalandunrelatedtothesizeoftheexternalpowerbridgetobecontrolled.
UsethisproceduretouseacontrolunitwithanexternalbridgenotincludedintheGefrancatalogue.
1) Conguredip-switchS15ontheCUregulationcard:
Standard American
S15-8 S15-7 S15-6 S15-5 S15-4 S15-3 S15-2 S15-1
TPD32-EV-CU-230/500-....-.... TPD32-EV-CU-230/500-....-....
OFF ON ON ON ON ON ON ON
TPD32-EV-CU-575/690-....-.... TPD32-EV-CU-575/690-....-....
ON OFF ON ON ON ON ON ON
2) Thedefaultvaluesofthefollowingparametersaresetautomatically:
• DriveSize(IPA465)=Fullloadcurr(IPA179)=4
• Nomuxcurr(IPA374)=1
• Inertia(IPA1015)=10
• Friction(IPA1014)=0.001
3) ModifytheDrive Sizeparameter(IPA465)tosetthedesiredsizedirectl.
imPortant: Inthiscongurationthemax.I2toverloadareasarealwayscalculatedas150%ofFull load
currx60secondsformotoroverloadand150%ofDrive sizex60secondsfordriveover-
load.
imPortant: TheSize selectionparameter(IPA464)cannotbesetinthisconguration.
