Table 4.3.4: Wire adapter Kit and lugs suggested for UL approval
Thefollowingsizesarenotprovidedwithpressureconnectors.Recommendedcompressionlugsareinthefol-
lowingtable.Forsizesupto56AanyULlistedlug,sizedfortheindicatedboltandAWGorMCMcable,is
suitableforthisuse,otherwiseacompressionlugtypefromILSCOorBURNDY(YA...)orGrainger(3L...)
manufacturerisspecied.
Device type Terminals AWG o MCM Lug type Bolt diameter [mm]
Tightening torque
[Nm]
TPD32-EV-.../...-17-....-A-NA U-V-W-C-D-PE 12 any 5 2-3
TPD32-EV-.../...-35-....-A-NA U-V-W-C-D-PE 8 any 5 2,5-3
TPD32-EV-.../...-56-....-A-NA U-V-W-C-D-PE 4 any 5 2,5-3
TPD32-EV-.../...-88-....-A-NA U-V-W-C-D-PE
See table belowTPD32-EV-.../...-112-....-A-NA U-V-W-C-D-PE
TPD32-EV-.../...-148-....-A-NA U-V-W-C-D-PE
TPD32-EV-.../...-224-..-B-NA
U-V-W 2 x 1 YA1CL6-BOX M10 25
C-D 2 x 2/0 YA26L6-BOX M10 25
PE M8 15
TPD32-EV-.../...-280-..-B-NA
U-V-W 2 x 2/0 YA26L6-BOX M10 25
C-D 2 x 3/0 YA27L-BOX M10 25
PE M8 15
TPD32-EV-.../...-336-..-B-NA
U-V-W 2 x 250 YA27L-BOX M10 25
C-D 2 x 3/0 YA29L-BOX M10 25
PE M8 15
TPD32-EV-.../...-400-..-B-NA
U-V-W 2 x 250 YA29L-BOX, M10 25
C-D 2 x 300; serve kit YA30L M10 25
PE M8 15
TPD32-EV-.../...-450-..-B-NA
U-V-W 2 x 300; serve kit YA30L7 M10 25
C-D 2 x 400; serve kit YA32L M10 25
PE M8 15
TPD32-EV-.../...-490-..-C-NA
U-V-W 3 x 3/0 YA27L-BOX M10 25
C-D 4 x 2/0 YA26L6-BOX M10 25
PE 1/0 YA25L6-BOX M8 15
TPD32-EV-.../...-560-..-C-NA
U-V-W 3 x 3/0 YA27L-BOX M10 25
C-D 4 x 2/0 YA26L6-BOX M10 25
PE M8 15
TPD32-EV-.../...-750-..-C-NA
U-V-W 4 x 4/0 YA28L-BOX 2 x M10 25
C-D 4 x 300, serve kit YA30L 2 x M10 25
PE 2/0 YA26L6-BOX M8 15
TPD32-EV-.../...-800-..-C-NA
U-V-W-C-D 4 x 250 CRA-250 o CRA-250L M10 25
PE M8 15
TPD32-EV-.../...-850-..-C-NA
U-V-W-C-D 4 x 300, serve kit CRA-300 o CRA-300L M10 25
PE M8 15
TPD32-EV-.../...-980-..-D-NA
U-V-W 4 x 300 3LM58 4 x M12 45
C-D 4 x 500 3LM61 4 x M12 45
PE 2 x 300 3LM58 4 x M12 45
TPD32-EV-.../...-1000-..-D-NA
U-V-W 4 x 350 3LM59 4 x M12 45
C-D 4 x 500 3LM61 4 x M12 45
PE 4 x 350 3LM59 4 x M12 45
TPD32-EV-.../...-1200-..-D-NA
U-V-W
4 x 500
with EAM 2617_1 adapter
3LM61 4 x M12 45
C-D
5 x 500
with EAM 2617_3 adapter
3LM61 4 x M12 45
PE 2 x 500 3LM61 4 x M12 45
TPD32-EV-.../...-1500-..-D-NA
U-V-W
5 x 500
with EAM 2617_1 adapter
3LM61 4 x M12 45
C-D
6 x 500
with EAM 2617_3 adapter
3LM61 4 x M12 45
PE 3 x 350 3LM59 4 x M12 45
TPD32-EV-.../...-1800-..-D-NA
U-V-W
6 x 500
with EAM 2617_1 adapter
3LM61 4 x M12 45
C-D Use Cu-bar or Eriflex "Flexibar" - 4 x M12 45
PE 3 x 500 3LM61 4 x M12 45
TPD32-EV-.../...-1850-..-D-NA
U-V-W
6 x 500
with EAM 2617_1 adapter
3LM61 4 x M12 45
C-D Use Cu-bar or Eriflex "Flexibar" - 4 x M12 45
PE 3 x 500 3LM61 4 x M12 45
2x meansthattwocompressionlugsofthespeciedtypehavetobeusedontheoppositesideofthebusbar.
4x meansthatfourcompressionlugsofthespeciedtypehavetobeusedonthesamebusbar,twoforeachsideandoneforeachbolthole.
 Bolt,nutsandwashersarefactorymountedonoutputbusbars.TherequiredILSCOcompressiontoolismarkedoneachterminalplug.
