—————— TPD32-EV ——————
476
A1.1 Models available and main technical data
Model name
Armature Field
Type of
drive
Rated U
ln Rated Udn Rated Idn Rated Ifn Rated Ulfn Rated Udfn
Mains input
voltage
Motor output
voltage
Motor output
current
Motor field
output current
Mains input
voltage
Motor field
output voltage
[quadrants] [
Vac] [Vdc] [Adc] [Adc] [Vac] [Vdc]
TPD32-EV-CU-230/500-THY1-40
2Q / 4Q
3 x 230 / 400
/ 500
up to 600
Can be set to
between 4 and
20,000 A
40
1 x 230 / 400
/ 460
200 / 310 / 360
TPD32-EV-CU-230/500-THY2-40
TPD32-EV-CU-230/500-THY1-70
70
TPD32-EV-CU-230/500-THY2-70
TPD32-EV-CU-575/690-THY1-40
3 x 575 / 690 up to 810
40
TPD32-EV-CU-575/690-THY2-40
TPD32-EV-CU-575/690-THY1-70
70
TPD32-EV-CU-575/690-THY2-70
note ! …-THY1-…modelsaresuitableforcontrollingpulsetransformerswithonesecondarywind-
ing;…-THY2-…modelsforcontrollingpulsetransformerswithtwosecondarywindings.
A1.2 Connection cables supplied
Allthemodelslistedabovearesuppliedwiththreecablesforconnectiontothepowerbridgeinstandardsitua-
tions.However,additionalcablesmaybenecessaryincertainconditions.Thesearedescribedbelow.Theow
chartandtablesbelowwillhelpyoudecidewhichcontrolunitisthebestforyourparticularapplicationand
whetheryouneedanyadditionalcables.
Table A.1.2.1: Connection cables for TPD32-EV-CU-….
Name Description
Supplied as
standard
Electrical diagram Code
KP Connector Interface Cable
for TPD32-EV-CU
Cable, 5-pin, AWG14, tot. length 2.5 m, sheathing for 1.5
m. Link between mains voltage and armature voltage. KP
connector
yes
"Figure 9.4.3-C:
ESE5799 (3/3) -
TPD32-EV-CU-" on
page 424
S72762
KPT31 Connector Interface
Cable for TPD32-EV-CU
Cable, 3 twisted pairs, 6-pin, AWG18, tot. length 2.5 m,
sheathing for 1.5 m. Link between current sensors (CT) and
thermal contact on power bridge(s). KPT31 connector
yes S72763
KPT11 Connector Interface
Cable for TPD32-EV-CU
Cable, 10-pin, AWG22, tot. length 2.5 m, sheathing for
1.5 m. Link between pulse transformers. KPT11 15-pin D
connector
yes S72764
KP Connector Adapter Cable
for TPD32-EV-CU
Cable, 5-pin, AWG14, tot. length 0.3 m with sheathing. The
cable is an adapter to allow a new TPD32-EV-CU-.. control
unit to be connected to replace an earlier version of the
TPD32 control unit. For KP connector
upon request
"Figure 9.4.3-B:
ESE5799 (2/3) -
TPD32-EV-CU-" on
page 423
S72760
KPT11 Connector Adapter
Cable for TPD32-EV-CU
Y-cable, 15-pin, AWG22, tot. length 0.3 m with sheathing.
The cable is an adapter to allow a new TPD32-EV-CU-..
control unit to be connected to replace an earlier version of
the TPD32 control unit. Connector KPT11 and KPT31 on the
TPD32-EV-CU-.. side, KPT11 on the TPD32 side
upon request S72761
note ! RefertodiagramESE5799onpage1/3forwiringbetweenthepowerbridgeandcontrolunit
usingthethreecablessupplied("Figure9.4.3-A:ESE5799(1/3)-TPD32-EV-CU-"onpage
422).
