gefran TPD32-EV-500 series - Figure 4.8.5: Encoder and Tachometer Connections

—————— TPD32-EV ——————
84
A+
A-
B+ B-
156 987
0V 5V
XE1
A+
A-
B+ B-
156 287
0V 24V
XE2
Sinus encoder
-
+
Digital encoder
T
Analog tacho
S4-1...8
Voltage setting by
Figure 4.8.5: Encoder and Tachometer Connections
Analog outputs
1
2
21 22 23 24
Digital outputs
1234
25 26 27 28 29 30
Supply
Digital inputs
37 31 32 33 34
1234
19 18
0 V 24
+ 24 V
0V
+24V
R-TPD32
Figure 4.8.6: Programmable Inputs/outputs with relay and contacts
note!  Toimprovethenoiseimmunityitisadvisabletoconnectthecommonoftheoutputs(terminals
22/24,25/37)withtheground(terminals10or20oftheregulationboard).Itisnotpossible,
theabovementionedcommonhavetobegroudedbymeansofa0,1µF/250Vcapacitor.
