—————— TPD32-EV ——————
310
SetGear box ratio equaltothereductionratiobetweenthemotorandthewinder/unwinder:
Gear box ratio =0.5
SetDancer constant tothevalueinmmcorrespondenttothetotalaccumulationofmaterialinthedancer:
Dancer constant=(

Lx x 
= (160x2)x2=640mm
M
Gear box ratio

L=160mm
WInder/Unwinder Dancer

L
Electrical 0
Central position
of working
One pitch dancer
Upper limit
switch=+1000 count
Lower limit
switch=-1000 count
Figure 6.16.3.11: Diameter calculation
MeasureofDancer constant:
SetthekeypadofthedriveontheparameterPID feed-back.
Measureandmultiplyby2,thedistancebetweenthelowermechanicalfullrangeandthepositionofthedancer
sothatintheparameterPID feed-back willdisplay0(positionof0electric).
Asthedancerhasonlyonepitch,multiplytheabovecalculatedvalueby2.
Inthiscaseset:
Dancer constant =640mm
ProgrammMinimum diameter equaltotheminimumvalueofthecorediameter[cm]:
Minimum diameter =10cm
