gefran TPD32-EV-500 series - Table 4.4.2-A: Dip-Switch S15 Adaptation of the Regulation Card to the Device Type

—————— TPD32-EV ——————
70
Table 4.4.2-A: Dip-switch S15 adaptation of the regulation card to the device type
Standard American S15-8 S15-7 S15-6 S15-5 S15-4 S15-3 S15-2 S15-1
TPD32-EV-500/600-20-..-A
TPD32-EV-FC-.../...-20-..-A
TPD32-EV-500/600-17-..-A-NA OFF ON OFF OFF OFF OFF OFF OFF
TPD32-EV-500/600-40-..-A
TPD32-EV-FC-.../...-40-..-A
TPD32-EV-500/600-35-..-A-NA OFF ON OFF OFF OFF OFF OFF ON
TPD32-EV-500/600-70-..-A
TPD32-EV-FC-.../...-70-..-A
TPD32-EV-500/600-56-..-A-NA OFF ON OFF OFF OFF OFF ON OFF
TPD32-EV-500/600-110-..-A
TPD32-EV-FC-.../...-110-..-A
TPD32-EV-500/600-88-..-A-NA OFF ON OFF OFF OFF OFF ON ON
TPD32-EV-500/600-140-..-A
TPD32-EV-FC-.../...-140-..-A
TPD32-EV-500/600-112-..-A-NA OFF ON OFF OFF OFF ON OFF OFF
TPD32-EV-500/600-185-..-A
TPD32-EV-FC-.../...-185-..-A
TPD32-EV-500/600-148-..-A-NA OFF ON OFF OFF OFF ON OFF ON
TPD32-EV-500/600-280-..-B
TPD32-EV-FC-.../...-280-..-B
TPD32-EV-500/600-224-..-B-NA OFF ON OFF OFF OFF ON ON OFF
TPD32-EV-500/600-350-..-B
TPD32-EV-FC-.../...-350-..-B
TPD32-EV-500/600-280-..-B-NA OFF ON OFF OFF OFF ON ON ON
TPD32-EV-500/600-420-..-B
TPD32-EV-FC-.../...-420-..-B
TPD32-EV-500/600-336-..-B-NA OFF ON OFF OFF ON OFF OFF OFF
TPD32-EV-500/600-500-..-B
TPD32-EV-FC-.../...-500-..-B
TPD32-EV-500/600-400-..-B-NA OFF ON OFF OFF ON OFF OFF ON
TPD32-EV-500/600-650-..-B
TPD32-EV-FC-.../...-650-..-B
TPD32-EV-500/600-450-..-B-NA OFF ON OFF OFF ON OFF ON OFF
note!  ForsizesTPD32-EV-.../...-...-..-E,dip-switchS15showninthetable(whichisfactory-set)
isontheregulationcardoftheTPD32-EV-CU-...associatedwiththeexternalbridge.
Standard American S15-8 S15-7 S15-6 S15-5 S15-4 S15-3 S15-2 S15-1
TPD32-EV-500/600-770-2B-C TPD32-EV-500/600-560-2B-C-NA
OFF ON OFF OFF ON OFF ON ON
TPD32-EV-500/600-1000-2B-C TPD32-EV-500/600-800-2B-C-NA
OFF ON OFF OFF ON ON OFF OFF
TPD32-EV-500/600-1400-2B-D TPD32-EV-500/600-1000-2B-D-NA
OFF ON ON OFF OFF OFF OFF OFF
TPD32-EV-500/600-1600-2B-D TPD32-EV-500/600-1200-2B-D-NA
OFF ON ON OFF OFF OFF OFF ON
TPD32-EV-500/600-2000-2B-D TPD32-EV-500/600-1500-2B-D-NA
OFF ON OFF ON OFF ON OFF OFF
TPD32-EV-500/600-2400-2B-D TPD32-EV-500/600-1850-2B-D-NA
OFF ON ON OFF OFF ON ON OFF
TPD32-EV-500/600-1200-2B-E TPD32-EV-500/600-1000-2B-E-NA
OFF ON OFF OFF ON ON OFF ON
TPD32-EV-500/600-1500-2B-E TPD32-EV-500/600-1300-2B-E-NA
OFF ON OFF ON OFF OFF OFF ON
TPD32-EV-500/600-1800-2B-E TPD32-EV-500/600-1400-2B-E-NA OFF ON OFF ON OFF OFF ON ON
TPD32-EV-500/600-2000-2B-E TPD32-EV-500/600-1500-2B-E-NA
OFF ON OFF ON OFF ON OFF OFF
TPD32-EV-500/600-2400-2B-E TPD32-EV-500/600-1800-2B-E-NA
OFF ON OFF ON OFF ON OFF ON
TPD32-EV-500/600-2700-2B-E TPD32-EV-500/600-2000-2B-E-NA
OFF ON OFF ON OFF ON ON OFF
TPD32-EV-500/600-2900-2B-E TPD32-EV-500/600-2200-2B-E-NA
OFF ON OFF ON OFF ON ON ON
TPD32-EV-500/600-3300-2B-E TPD32-EV-500/600-2350-2B-E-NA
OFF ON OFF ON ON OFF OFF OFF
TPD32-EV-575/680-280-2B-B TPD32-EV-575/680-224-2B-B-NA
ON OFF OFF OFF OFF ON ON OFF
TPD32-EV-575/680-350-2B-B TPD32-EV-575/680-280-2B-B-NA
ON OFF OFF OFF OFF ON ON ON
TPD32-EV-575/680-420-2B-B TPD32-EV-575/680-336-2B-B-NA
ON OFF OFF OFF ON OFF OFF OFF
TPD32-EV-575/680-500-2B-B TPD32-EV-575/680-400-2B-B-NA
ON OFF OFF OFF ON OFF OFF ON
TPD32-EV-575/680-650-2B-B TPD32-EV-575/680-450-2B-B-NA
ON OFF OFF OFF ON OFF ON OFF
TPD32-EV-575/680-700-2B-C TPD32-EV-575/680-490-2B-C-NA
ON OFF OFF ON ON OFF ON ON
TPD32-EV-575/680-1000-2B-C TPD32-EV-575/680-750-2B-C-NA
ON OFF OFF ON ON ON OFF ON
TPD32-EV-575/680-1300-2B-D TPD32-EV-575/680-980-2B-D-NA
ON OFF OFF ON ON ON ON ON
TPD32-EV-575/680-1600-2B-D TPD32-EV-575/680-1200-2B-D-NA
ON OFF ON OFF OFF OFF OFF ON
TPD32-EV-575/680-2000-2B-D TPD32-EV-575/680-1500-2B-D-NA
ON OFF OFF ON OFF ON OFF OFF
TPD32-EV-575/680-2300-2B-D TPD32-EV-575/680-1800-2B-D-NA
ON OFF ON OFF OFF ON OFF ON
TPD32-EV-690/810-560-2B-C TPD32-EV-690/810-360-2B-C-NA
ON OFF OFF ON ON OFF ON OFF
TPD32-EV-690/810-700-2B-C TPD32-EV-690/810-490-2B-C-NA
ON OFF OFF ON ON OFF ON ON
TPD32-EV-690/810-900-2B-C TPD32-EV-690/810-650-2B-C-NA ON OFF OFF ON ON ON OFF OFF
TPD32-EV-690/810-1300-2B-D TPD32-EV-690/810-920-2B-D-NA
ON OFF OFF ON ON ON ON OFF
TPD32-EV-690/810-1600-2B-D TPD32-EV-690/810-1200-2B-D-NA
ON OFF ON OFF OFF OFF OFF ON
TPD32-EV-690/810-1900-2B-D TPD32-EV-690/810-1450-2B-D-NA
ON OFF ON OFF OFF OFF ON ON
TPD32-EV-690/810-2100-2B-D TPD32-EV-690/810-1650-2B-D-NA
ON OFF ON OFF OFF ON OFF OFF
TPD32-EV-690/810-1010-2B-E TPD32-EV-690/810-900-2B-E-NA
ON OFF OFF OFF ON ON ON ON
TPD32-EV-690/810-1400-2B-E TPD32-EV-690/810-1150-2B-E-NA
ON OFF OFF ON OFF OFF OFF OFF
TPD32-EV-690/810-1700-2B-E TPD32-EV-690/810-1350-2B-E-NA ON OFF OFF ON OFF OFF ON OFF
