TPD32-EV-.../...-2200-2B-E 2200 A 4400 A TPD32-EV-.../...-2900-2B-E 2900 A 5800 A 70 A
TPD32-EV-.../...-2350-..-E 2350 A 4700 A TPD32-EV-.../...-3300-..-E 3300 A 6600 A 70 A
* Currentreductionforhighertemperatures,seesection3.1,“Permissibleambientconditions”.   
** Theoverloadsizeanddurationdependontheoverloadcycle,seesection6.14.6,“Overloadcontrol”.
note!  Theeldmotorcurrentcansometimesbeverysmallcomparedwithratedeldcurrentof
theconverter.InordertoprovideregulationduringVoltagecontrolofthemotor,followthe
describedinstructionstochangetheFluxcurrentmaxoftheconverter.InthiscasetheNom
eld scaleparametermustbesetwiththenewratedeldcurrentvalue
.
Table 2.3.3.2: TPD32-EV-FC Output currents
Type Field converter
(Terminals C/D)
Continuous curr. IdN
with Ta = 40°C (104°F)
(*)
Max. current
(with overload)
(**)
TPD32-EV-FC-.../...-20-..-A 20 A 40 A
TPD32-EV-FC-.../...-40-..-A 40 A 80 A
TPD32-EV-FC-.../...-70-..-A 70 A 140 A
TPD32-EV-FC-.../...-110-..-A 110 A 220 A
TPD32-EV-FC-.../...-140-..-A 140 A 280 A
TPD32-EV-FC-.../...-185-..-A
185 A 370 A
TPD32-EV-FC-.../...-280-..-B 280 A 560 A
TPD32-EV-FC-.../...-350-..-B 350 A 700 A
TPD32-EV-FC-.../...-420-..-B 420 A 840 A
TPD32-EV-FC-.../...-500-..-B 500 A 1000 A
TPD32-EV-FC-.../...-650-..-B 650 A 1300 A
Table 2.3.3.3: TPD32-EV-CU Output currents
Type Armature current (***) Field converter
(Terminals C1 / D1)
(Terminals C/D)
Continuous current
(***) (settable)
I
dN
with Ta = 40°C (104°F)
(*)
Max. current
(with overload)
(**)
Continuous curr. IFN with Ta =
40°C
*
TPD32-EV-CU-.../....-THY1-40
4 .... 20000 A
(currents range managed by CU)
up to 200%
40 A
TPD32-EV-CU-.../....-THY2-40 40 A
TPD32-EV-CU-.../...-THY1-70 70 A
TPD32-EV-CU-.../...-THY2-70 70 A
* Currentreductionforhighertemperatures,seesection3.1,“Permissibleambientconditions”.   
** Theoverloadsizeanddurationdependontheoverloadcycle,seesection6.14.6,“Overloadcontrol”.
*** Externalpowerbridge.
