—————— TPD32-EV ——————
192
Index storing parameter [13]
No. bit Name Description Access
(Read/Write)
Default
0 Source Enc
Num
Itindicatestowhichencoderthevaluesinthisregisterarereferredto:
0=registerdataarereferredtotheEncoder1
1=registerdataarereferredtotheEncoder2
R 0
1 MP_IN
ActualQualierlevelvalue:
0=qualierinputlevelislow
1=qualierinputlevelishigh
R 0
2-3 STATNLT
Statusoftheacquisitionfunction:
0=Switchedoff
1=Once,storingisnotexecutedyet
2=Once,storingisalreadyexecuted
3=Continuous
R 0
16-31 CNTNLT
Positioncountervaluecorrespondingtotheindex.0=Switchedoff
ValueisonlyvalidwhenSTANLTisequalto2or3
R 0
