gefran TPD32-EV-500 series - Table 4.3.6: Cable Size for Power Field Terminals U1, V1, C1, D1

—————— TPD32-EV ——————
68
Device type Terminals Wire adapter kit Recommended lugs
type Kit bolt size
[mm]
Tightening
torque [Nm]
ILSCO type Burndy type Grainger type
TPD32-EV-.../...-1200-..-D-NA
U, V, W EAM2617_1 4 x M12 45 - - 3LM57
C, D EAM2617_3 4 x M12 45 - - 3LM61
PE - 4 x M12 45 - - -
TPD32-EV-.../...-1500-..-D-NA
U, V, W EAM2617_1 4 x M12 45 - - 3LM57
C, D EAM2617_3 4 x M12 45 - - 3LM61
PE 4 x M12 45 - -
TPD32-EV-.../...-1800-..-D-NA
U, V, W EAM2617_1 4 x M12 45 - - 3LM57
C, D Use busbar 4 x M12 45 - - 3LM61
PE 4 x M12 45 - -
TPD32-EV-.../...-1850-..-D-NA
U, V, W EAM2617_1 4 x M12 45 - - 3LM57
C, D Use busbar 4 x M12 45 - - 3LM61
PE 4 x M12 45 - -
note! Thecablecrosssectiontobeconnectedmustbedimensionedanddeterminedbythedesigner
thathastotakeintoaccountthecurrent,thetemperatureandthecableposition.Thevalues
indicatedonthetablearereferredtothemaximumcrosssectionacceptedbyitsterminals;
theyarenottheindicationaboutthecabledimensiontobeconnected!
Caution!  Thecurrentintheprotectiveconductorofthemotorcablecanbeuptotwicethevalueofthe
ratedcurrent
I
dN
ifthereisanearthfaultattheoutputoftheTPD32converter .
note! ForfurtherdetailsaboutKitssee"A3.1EAMAdapterKit"onpage501,onthesedrawings
itispossibletoindicatealternativewireterminalstothoseinthetable.
Table 4.3.6: Cable size for power field terminals U1, V1, C1, D1
American Standard max cable section [mm
2
] AWG Tightening torque [Nm]
TPD32-EV-.../...-17-..-A
...
TPD32-EV-.../...-850-4B-C
TPD32-EV-.../...-20-..-A
...
TPD32-EV-500/...-1050-4B-C
0,2...4 24...10 0,5...0,8
TPD32-EV-.../...-920-2B-D TPD32-EV-690/...-1300-2B-D
10... 16 6 ... 3 4
TPD32-EV-.../...-980-..-D
...
TPD32-EV-.../...-1850-..-D
TPD32-EV-575/...-1300-..-D
...
TPD32-EV-.../...-2400-..-D
Table 4.3.7: Cable size for fans, signals, thermistors and regulation supply
Terminals Max connection cable section Tightening torque [Nm]
flexible [mm
2
] multi-core [mm
2
] AWG
PE 2,5...10 2,5...10 12...8 2
U2, U3, V2, V3, 31, 32, 35, 36, 75, 76, 78, 79 0,14...1,5 0,14...2,5 26...14 0,5
