E4 Separator
Spare Parts
E4 Separator
Item
Part No.
Description
-
1434693
Separator assy
1
1456978
Scoop assy
2
1456979
Separator tongue
3
1446567
Collar screw
4
1456980
Spacer ring
5
1462883
Compression spring
6
1462884
Pneumatic cylinder assy
7
1456950
One-way restrictor assy
8
1457041
Chute assy
9
1445548
Proximity switch NS5
10
1456973
Proximity switch NS4
11
1445682
Proximity switch NS1
12
1457050
Y-connection assy
E4
7
4
5
12
11
10
3
1
2
9
- 13 -
6
8
