10.1 Maintenance Information
Grease
Jaws
Stop ring
Washer
Jaw housing
Caution!
Maintenance
10.1 Maintenance Information
Observe safety information!
Wear safety goggles!
D a i l y:
 To lubricate/replace jaws
- Switch off "POWER" master switch.
- Unscrew spreader nosepiece 2-80.
- Remove closing sleeve 2-8022 and unscrew jaw housing.
- Remove set of jaws with washer, stop ring and opening
springs.
- Replace jaws if necessary.
- Lightly grease sliding surface of jaw housing (roller bearing
grease).
- Fit jaw housing over the set of jaws, insert stop ring and
washer.
- Install in reverse order of removal.
- Switch on "POWER" master switch, press "ON" button.
 To check/replace leaf spring
- Press "ON" button.
- Select "MAN" mode.
- Execute "Stroke position" function.
- Remove mandrel guide.
- Check that the leaf spring visible in the
mandrel eject slot is seated and ten-
sioned correctly.
- Replace leaf spring if necessary (see
Section 21 "Blind Riveting Gun Repair
Instructions").
 To refill central lubrication system
- Remove screw plug.
- Top up oil level to max. 5 mm below top edge of
sight glass.
- Tighten screw plug.
Leaf spring
10
Screw plug
