Major Hardware Components TRIND Overhead Antennas
Page 4-16 MDE-3664B TRIND® Start-up, Service, and Parts Manual · June 2013
Mobil Overhead Antenna Bracket Assemblies (T20231) and Hardware for
The Advantage Series
Following table lists the Mobil Overhead Antenna Bracket Assemblies and hardware for The
Advantage Series:
Item Description
Wide Frame
Single-sid
ed
Wide Frame
Double-sided
Narrow Frame
Single-sided
Narrow Frame
Double-sided
1 Antenna Top Cover T20213-01 T20213-01 T20215-01 T20215-01
2 Bracket, Universal Antenna T20212-01 T20212-01 T20212-01 T20212-01
3 Bracket, Antenna Mounting T20211-01 T20211-01 T20211-01 T20211-01
3a Bracket, Antenna Mounting (see note) T20211-02 - T20211-02 -
4 Screw, 10-32 Black K85736-45 K85736-45 K85736-45 K85736-45
5 Antenna Assembly T20231-G1 T20231-G1 T20231-G1 T20231-G1
6 1/4-20 Bolt x 4” Black K01914-70 K01914-70 K01914-70 K01914-70
7 1/4-20 Nut, Black Q11890-08 Q11890-08 Q11890-08 Q11890-08
8 Over Head Antenna Cables R20509-G1
Q13578
-01
R20509-
G1
Q13578-01
R20509-G1
Q13578-01
R20509-G1
Q13578-01
9 Connector, Tube Fitting Q13591-01 Q13591-01 Q13591-01 Q13591-01
10 Conduit, Flexible Black Plastic Q13592-02 Q13592-02 Q13592-02 Q13592-02
Note: Not shown on page 4-16, single-sided antenna bracket has no antenna mounting arms.
Mobil Overhead Antenna Bracket Assemblies and Hardware for MPD-3
Following table lists the Mobil Overhead Antenna Bracket Assemblies and hardware for
MPD-3:
Item Description
PMI Bezel
Single-sided
PMI Bezel
Double-sided
Mack Bezel
Single-sided
Mack Bezel
Double-sided
1 Antenna Top Cover T20214-01 T20214-01 T20214-01 T20214-01
2 Bracket, Universal Antenna T20212-01 T20212-01 T20212-01 T20212-01
3 Bracket, Antenna Mounting T20211-01 T20211-01 T20211-01 T20211-01
3a Bracket, Antenna Mounting (see note) T20211-02 - T20211-02 -
4 Screw, 10-32 Black K85736-45 K85736-45 K85736-45 K85736-45
5 Antenna Assembly T20231-G1 T20231-G1 T20231-G1 T20231-G1
6 1/4-20 Bolt x 4” Black K01914-70 K01914-70 K01914-70 K01914-70
7 1/4-20 Nut, Black Q11890-08
Q11890-08 Q11890-08 Q11890-08
8 Over Head Antenna Cables R20509-G1
Q13578-01
R
20509-G1
Q13578-01
R20509-G1
Q13578-01
R20509-G1
Q13578-01
9 Connector, Tube Fitting Q13591-01 Q13591-01 Q13591-01 Q13591-01
10 Conduit, Flexible Black Plastic Q13592-02 Q13592-02 Q13592-02 Q13592-02
Note: Not shown on page 4-16, single-sided antenna bracket has no antenna mounting arms.
