Major Hardware Components TRIND Overhead Antennas
Page 4-20 MDE-3664B TRIND® Start-up, Service, and Parts Manual · June 2013
Single-loop Antenna Assembly Bracket Kits for The Advantage Series
Following table lists the Single-loop Antenna Assembly Bracket Kits for The Advantage
Series parts:
Item Description
W/F & N/F RID
Plus Exxon
(K
96647-01)
With Canopy
(K96647-02)
With
Or With
Out
Blue Hats
(K96647-03)
With Milwaukee
Light Box
(K96647-06)
1 Antenna Bracket, Left T20623-01 T20624-01 - -
2 Antenna Bracket, Right T20623-02 T20624-02 - -
1 Antenna Bracket, W/F & N/F - - T20625-01 -
2 Antenna Bracket, W/F & N/F - - T20625-02 -
1 Antenna Bracket, ADV & MPD-3 - - - T20628-01
2 Antenna Bracket, ADV & MPD-3 - - - T20628-02
3 Gasket, Mounting Bracket N23958-01 N23958-01 N23958-01 N23958-01
4 Gasket, Antenna Wire Bracket N23959-01 N23959-01 N23959-01 N23959-01
5 Screw, Hex Head Q11889-104 Q11889-104 Q11889-104 Q11889-104
6 Fastener, Self-Drilling - - - Q13897-01
Single-loop Antenna Assembly Bracket Kits for MPD-3 Series
Following table lists the Single-loop Antenna Assembly Bracket Kits for MPD-3 Series parts:
Item Description
With Canopy
(K96647-04)
W
ith Out
C
a
nopy
(K96647-05)
With Milwaukee
Lig
ht Box
(K96647-06)
1 Antenna Bracket, Left T20626-01 T20627-01 -
2 Antenna Bracket, Right T20626-02 T20627-02 -
1 Antenna Bracket, ADV and MPD-3 - - T20628-01
2 Antenna Bracket, ADV and MPD-3 - - T20628-02
3 Gasket, Mounting Bracket N23958-01 N23958-01 N23958-01
4 Gasket, Antenna Wire Bracket N23959-01 N23959-01 N23959-01
6 Screw, Hex Head Q11889-104 Q11889-104 Q11889-104
6 Fastener, Self-Drilling - - Q13897-01
Single-loop Antenna Assembly Bracket Kit for Encore Unit
Following table lists the Single-loop Antenna Assembly Bracket Kits for Encore units parts:
Item Description K96647-07
1 Antenna Bracket, Encore T20630-01
2 Antenna Bracket, Encore T20630-02
3 Gasket, Bracket Mounting N23958-01
4 Gasket, Antenna Wire Bracket N23959-01
5 Screw, Hex Head
Q11889-104
