Starting up/Setup mode
54 A0293_06_E00_03 HBM: public MP85A
3. Status of digital inputs and outputs
The MP85A(-S) has 5 inputs and 8 outputs.
The MP85ADP(‐S) and MP85ADP-PN(-S) have 1 input and 4 outputs.
S Input
set, not set
S Output
set, not set
4. PROFIBUS status (MP85ADP(-S) and MP85ADP-PN(-S) only)
BD_SEAR (baud rate search)
WT_PARM (waiting for parameterization)
WT_CONF (waiting for configuration)
DATA_EX (cyclic data traffic)
ERROR (bus error)
5. Status of the memory card (MMC/SD Card)
Using the optional memory card, you can choose to save measured curves,
measurement results and/or parameter sets (measurement programs).
You can use either an SD card or a MultiMedia (MMC) card up to 2GB. Use
the PME Assistant (“Data backup” menu) to select what to save and on which
medium (memory card or PC).
You can save up to 300,000 measured curves on a memory card with 1GB
storage capacity. In addition, you can save up to 31 parameter sets in XML
format and up to 1000 parameter sets in binary format.
You can upload parameter sets in XML format to the device using the key
board. Binary parameter sets can only be uploaded using the PME Assistant or
the interface.
