HEIDENHAIN MANUALPLUS 620 User Manual

428 DIN Programming for the Y Axis
5.8 Example Program
Example: “Y axis [EX_Y.NC]”
HEADER
#MATERIAL Aluminum
#WORKPIECE Example Y axis
#MEASURE_UNITS Metric
TURRET 1
T1 ID"Roughing 80 G."
T2 ID"NC center drill"
T3 ID"Finishing 35 G."
T4 ID"Drill 5.2mm"
T5 ID"Thread outside"
T6 ID"Tapping M6".
T8 ID"Mill D16mm"
T10 ID"Mill D6mm"
T12 ID"Deburring_m"
BLANK
N 1 G20 X70 Z97 K1
FINISHED
N 2 G0 X0 Z0
N 3 G1 X30 BR-2
N 4 G1 Z-20
N 5 G25 H7 I1.5 K7 R1 W30 FP2 [Undercut DIN 76]
N 6 G1 X56 BR-1
N 7 G1 Z-60
N 8 G1 X64 BR-1
N 9 G1 Z-75 BR-1
N 10 G1 X44 BR3
N 11 G1 Z-95 BR-1
N 12 G1 X0
N 13 G1 Z0
LATERAL_Y X56 C0 [Define YZ plane]
N 14 G308 ID“Surface"
N 15 G386 Z-55 Ki8 B30 X56 C0 [Single surface]
N 16 G308 ID“Slot 10mm“ P-2
N 17 G381 Z-40 Y0 A90 K50 B10 [Linear slot on single surface]
