HEIDENHAIN MANUALplus 620 429
5.8 Example Program
N 18 G309
N 19 G308 ID“Hole_1 M6“ P-15
N 20 G481 Q2 Z-30 Y15 K-30 J-15 [Linear pattern on single surface]
N 21 G380 B5.2 P15 W118 I6 J10 F1 V0 o7 [Drilling, tapping, centering]
N 22 G309
N 23 G308 ID“Hole_2 M6“ P-15
N 24 G481 Q2 Z-50 Y15 K-50 J-15 [Linear pattern on single surface]
N 25 G380 B5.2 P15 W118 I6 J10 F1 V0 O7 [Drilling, tapping, centering]
N 26 G309
N 27 G309
MACHINING
N 28 UNIT ID“START“ [Start of program]
N 30 G26 S3500
N 31 G126 S2000
N 32 G59 Z256
N 33 G140 D1 X400 Y0 Z500
N 34 G14 Q0 D1
N 35 END_OF_UNIT
N 36 UNIT ID“G820_ICP“ [G820 Transverse roughing, ICP]
N 38 T1
N 39 G96 S220 G95 F0.35 M3
N 40 M8
N 41 G0 X72 Z2
N 42 G47 P2
N 43 G820 NS3 NE3 P2 I0 K0 H0 Q0 V3 D0
N 44 G47 M9
N 45 END_OF_UNIT
N 46 UNIT ID“G810_ICP“ [G810 Longitudinal roughing, ICP]
N 48 T1
N 49 G96 S220 G95 F0.35 M3
N 50 M8
N 51 G0 X72 Z2
N 52 G47 P2
N 53 G810 NS4 NE9 P3 I0.5 K0.2 H0 Q0 V0 D0
N 54 G14 Q0 D1
