430 DIN Programming for the Y Axis
5.8 Example Program
N 55 G47 M9
N 56 END_OF_UNIT
N 57 UNIT ID“G890_ICP“
[G890 Contouring in ICP]
N 59 T3
N 60 G96 S260 G95 F0.18 M4
N 61 M8
N 62 G0 X72 Z2
N 63 G47 P2
N 64 G890 NS4 NE9 V1 Q0 H3 O0 B0
N 65 G14 Q0 D1
N 66 G47 M9
N 67 END_OF_UNIT
N 68 UNIT ID“G32_MAN“
[G32 Cylindrical thread, direct]
N 70 T5
N 71 G97 S800 M3
N 72 M8
N 73 G0 X30 Z5
N 74 G47 P2
N 75 G32 X30 Z-19 F1.5 BD0 IC8 H0 V0
N 76 G14 Q0 D1
N 77 G47 M9
N 78 END_OF_UNIT
N 79 UNIT ID“C_AXIS_ON“
[C axis on]
N 81 M14
N 82 G110 C0
N 83 END_OF_UNIT
N 84 UNIT ID“G841_Y_MANT“
[Single surface in Y axis, latrl.]
N 86 T8
N 87 G197 S1200 G195 F0.25 M104
N 88 M8
N 89 G19
N 90 G110 C0
N 91 G0 Y0
N 92 G0 X74 Z10
