432 DIN Programming for the Y Axis
5.8 Example Program
N 131 T2
N 132 G197 S1000 G195 F0.22 M104
N 133 M8
N 134 G147 K2
N 135 G72 ID“Hole_1 M6“ D0
[Center the holes of the first pattern]
N 136 G47 M9
N 137 END_OF_UNIT
N 138 UNIT ID“G72_ICP_Y“
[ICP boring, countersinking in Y]
N 140 T2
N 141 G197 S1000 G195 F0.22 M104
N 142 M8
N 143 G147 K2
N 144 G72 ID“Hole_2 M6“ D0
[Center the holes of the second pattern]
N 145 G47 M9
N 146 G14 Q0 D1
N 147 END_OF_UNIT
N 148 UNIT ID“G74_ICP_Y“
[ICP drilling in Y axis]
N 150 T4
N 151 G197 S1200 G195 F0.24 M103
N 152 M8
N 153 G147 K2
N 154 G74 ID“Hole_1 M6“ D0 V2
[Holes of the first pattern]
N 155 G47 M9
N 156 END_OF_UNIT
N 157 UNIT ID“G74_ICP_Y“
[ICP drilling in Y axis]
N 159 T4
N 160 G197 S1200 G195 F0.24 M103
N 161 M8
N 162 G147 K2
N 163 G74 ID“Hole_2 M6“ D0 V2
[Holes of the second pattern]
N 164 G47 M9
N 165 G14 Q0 D1
N 166 END_OF_UNIT
N 167 UNIT ID“G73_ICP_Y“
[ICP tapping in Y axis]
