134
FIGURE 6-11
g)
If the Failed QC Comment setting is set to
“Entry Required” (see
3.
4
.3 QC T
est
Settings
) and the QC T
est has failed, then
FIGURE 6-11
will be displayed when the
Confirm button shown in
FIGURE 6-10
is
pressed. Use the Previous Image
button(9) to go back and add at least one
comment.
9
Previous Image button
QC Level 1
Result
a Failed QC
Enter at Least
one Comment for
9
138
140
Table of Contents
Table of Contents
2
Part I
6
Introduction
6
Introduction
7
Abbreviations/Glossary
8
Designated Terminology
11
Functional Description
13
System Components
13
Analyzer Overview
14
Docking Station - General
17
Docking Station Overview
19
Functions and Features
24
General Operations
25
How to Operate the Display
25
Display Buttons
25
Operating the Analyzer
29
Start up
29
Login Image
30
Main Menu and Help
31
Power Saver Mode
31
Display Buttons and Symbols
32
Navigation Buttons
32
Procedure Buttons
33
Other Display Buttons
34
Display Symbols
37
Entering Information with Letters and Digits
38
Entering Information from Barcodes
40
Settings
41
Settings
42
Activating the Settings Procedure
42
Define Lists
45
Liquid Controls
46
Cuvette Batches
52
Define Operators
56
Define Comments
61
Define Log Notes
63
Basic Settings
65
Date/Time
66
Power Saver
68
Audible Signals
69
Language
70
Advanced Settings
71
General Settings
72
Patient Test Settings
80
QC Test Settings
92
Linearity Test Settings
102
Default Settings
103
Infra Red
104
The Transmitting Analyzer
104
The Receiving Analyzer
106
Docking Station Settings
107
PART III Routine Use
108
Patient Test Procedure
109
Patient Test
109
Patient Test Result
115
Verify/Duplicate Sampling
117
Entering Comments
120
Entering Comments - Verified Sample
124
STAT Test Procedure
126
STAT Test
126
STAT Test Result
129
QC Test Procedure
130
Events Necessitating QC Tests
130
QC Reminder
130
QC Lockout
132
Supervisory Lockout
133
Performing a QC Test
134
QC Tests at a Specific Concentration Level
136
Linearity Test
141
Proficiency Test
150
Reviewing Stored Data
152
Activating the Stored Data Procedure
152
Review Stored Data
155
Review All Data
156
Review PAT/STAT
157
Review QC Tests
159
Review Analyzer Log
165
Delete Stored Data
167
Review Latest Download
169
Log Input
170
Data Communications
171
Interaction Application - Analyzer
171
Docking Station Setup
172
Data Transfer
178
Other Actions
181
Troubleshooting
182
Miscellaneous
192
Specifications
193
Technical Specifications
193
Analyzer
193
Docking Station
194
EMC and Electrical Safety
194
IVD Medical Device Directive
195
Warranty
195
Service and Disposal
195
Spare Parts
195
Optional Items
195
Symbols Used
196
Default Settings
198
Other manuals for HemoCue 201 DM
Manual
124 pages
