HemoCue 201 DM Reference Manual

42
Control Name
(Level 1)
123123ABCABC
4
5
6
7
2
3
GlucoTrol NG
FIGURE 3-8
The control level(2) and the currently used
name(3) of the Liquid Control are displayed.
If no information had been entered
previously, the Liquid Control name(3) will
not appear.
If the Confirm button is repeatedly pressed
through FIGURE 3-8 to FIGURE 3-11, no
changes will be eected.
d) Enter Liquid Control name(3) either
directly on the Display via the Text
mode(4) and Numeric mode(5) buttons,
or with the Barcode Scanner via the
Barcode Scanner button(6).
e) Press the Confirm button(7).
2 Liquid Control concentration level
3 Liquid Control name
4 Text mode button
5 Numeric mode button
6 Barcode Scanner button
7 Confirm button
