Symbols
Progressa® Bed Instructions for Use (171528 REV 9) 11
Additional GCI Symbols (see “Graphical Caregiver Interface (GCI)® Controls” on page 27).
Radio Equipment Directive 2014/53/EU on the Wireless Connectivity
module) (refer to “Wireless Connectivity” on page 53).
Wireless indicator (on the Wireless Connectivity module)—identifies the
connection status of the wireless module to the facility wireless network
(refer to “Wireless Connectivity” on page 53).
Connected indicator (on the Wireless Connectivity module)—identifies the
connection status of the wireless module to NaviCare® SmartSync® System
(refer to “Wireless Connectivity” on page 53).
Location indicator (on the Wireless Connectivity module)—identifies the
connection status of the Location feature (refer to “Wireless Connectivity”
on page 53).
Symbol Description
