APM

This section applies only to devices with an Accessory Power Management (APM) stand. The APM is

an accessory stand with work surface, power supply for enhanced device run time, and

organizational bins to arrange sensors and cables for available parameters.

Front-Top-Left view

No. Feature Description

1 Battery compartment (behind cover) Houses the battery

2 Battery charge status indicator Indicates charge level of battery

3 Light power switch Powers light under APM work surface

Service manual Controls, indicators, and connectors 21
