HIMax System 2 Safety
HI 801 001 E Rev. 4.01 Page 11 of 122
2.1.3 Operating Requirements
The devices have been developed to meet the following standards for EMC, climatic and
environmental requirements:
Standard Content
IEC/EN 61131-2 Programmable controllers, Part 2
Equipment requirements and tests
IEC/EN 61000-6-2 EMC
Generic standards, Parts 6-2
Immunity for industrial environments
IEC/EN 61000-6-4 Electromagnetic Compatibility (EMC)
Generic emission standard, industrial environments
Table 1: Standards for EMC, Climatic and Environmental Requirements
When using the safety-related HIMax control systems, the following general requirements
must be met:
Requirement type Requirement content
Protection class Protection class II in accordance with IEC/EN 61131-2
Pollution Pollution degree II in accordance with IEC/EN 61131-2
Altitude < 2000 m
Housing Standard: IP20/IP00
If required by the relevant application standards (e.g., EN 60204),
the device must be installed in an enclosure of the specified protec-
tion class (e.g., IP54).
Table 2: General requirements
Climatic Requirements
The following table lists the key tests and thresholds for climatic requirements:
IEC/EN 61131-2 Climatic tests
Operating temperature: 0...+60 °C
(test limits: -10...+70 °C)
Storage temperature: -40...+85 °C
Dry heat and cold resistance tests:
+70 °C / -25 °C, 96 h, power supply not connected
Temperature change, resistance and immunity test:
-25 °C / +70 °C und 0 °C / +55 °C,
power supply not connected
Cyclic damp-heat withstand tests:
+25 °C / +55 °C, 95 % relative humidity,
power supply not connected
Table 3: Climatic Requirements
Mechanical Requirements
The following table lists the key tests and thresholds for mechanical requirements:
IEC/EN 61131-2 Mechanical tests
Vibration immunity test:
5...9 Hz / 3.5 mm amplitude
9...150 Hz, 1 g, EUT in operation, 10 cycles per axis
Shock immunity test:
15 g, 11 ms, EUT in operation, 3 shocks per axis and direction (18
shocks)
Table 4: Mechanical Tests
