HIMA HIMax User Manual

3 Product Description HIMax System
HI 801 001 E Rev. 4.01 Page 30 of 122
Rack 0 Connected to Port 1 of Switch
Racks 1, 2, 3 Connected to Port 2 of
Switch A
Racks 4, 5, 6 Connected to Port 3 of
Switch A
Racks 7, 8, 9 Connected to Port 4 of
Switch A
Racks 10, 11, 12 Connected to Port 5
of Switch A
Rack 14 Connected to Port 3 of
Switch C
Rack 15 Connected to Port 4 of
Switch A
Switch C: Hirschmann SPIDER II Giga
5T/2S EEC Rail Switch with Port Num-
ber
Switch B: Hirschmann SPIDER II Giga
5T/2S EEC Rail Switch with Port Num-
ber
Rack 13 Connected to Port 2 of
Switch C
10 km Fiber Optic Cable
Switch A: Hirschmann SPIDER II Giga
5T/2S EEC Rail Switch with Port Num-
ber
Figure 8: Example for Calculating the System Bus Latency
