HIMax System 3 Product Description
HI 801 001 E Rev. 4.01 Page 29 of 122
The PADT can only be connected to a system bus module, which is located in a base
plate allowed for communication modules.
The network parameters such as switch latency or damping are indicated in the
specifications or must be determined through a measurement, and then be used in the
calculation.
i
When designing the network structure and calculating the maximum latency, HIMA
recommends to consult a network expert .
Example for Calculating a User-Specific Maximum Latency
The racks in Figure 8 are respectively connected to one another and to the switches with
100 m copper cable. 10 km fiber optic cable is used to connect the switches to one another.
