2 Safety HIMax System
HI 801 001 E Rev. 4.01 Page 12 of 122
EMC Requirements
Higher interference levels are required for safety-related systems. HIMax systems meet
these requirements in accordance with IEC 62061 and IEC 61326-3-1.
See column 'Criterion FS' (Functional Safety).
Test standards Interference immunity tests
Criterion
FS
IEC/EN 61000-4-2 ESD test: 6 kV contact, 8 kV air discharge 6 kV, 8 kV
IEC/EN 61000-4-3 RFI test (10 V/m): 80 MHz...2 GHz, 80 % AM
RFI test (3 V/m): 2 GHz...3 GHz, 80 % AM
RFI test (20 V/m): 80 MHz...1 GHz, 80 % AM
-
-
20 V/m
IEC/EN 61000-4-4 Burst test
Power lines: 2 kV and 4 kV
Signal lines: 2 kV
4 kV
2 kV
IEC/EN 61000-4-12 Damped oscillatory wave test
2.5 kV L-,L+ / PE
1 kV L+ / L -
-
-
IEC/EN 61000-4-6 High frequency, asymmetrical
10 V, 150 kHz...80 MHz, 80 % AM
20 V, ISM frequencies, 80 % AM
10 V
-
IEC/EN 61000-4-3 900 MHz pulses -
IEC/EN 61000-4-5 Surge:
Power lines: 2 kV CM, 1 kV DM
Signal lines: 2 kV CM, 1 kV DM at AC I/O
2 kV / 1 kV
2 kV
Table 5: Interference Immunity Tests
IEC/EN 61000-6-4 Noise emission tests
EN 55011
Class A
Emission test:
radiated, conducted
Table 6: Noise Emission Tests
