HIMax System 8 Specifications, Dimensioning
HI 801 001 E Rev. 4.01 Page 91 of 122
8 Specifications, Dimensioning
Applicable per project Value from ... to
Number of resources (controllers) 1...65 534
Per ressource Value from ... to
Number of base plates 1...16
Number of I/O modules 0...200
Number of I/O elements (sensors, actuators) 0...12 800
Maximum length of a system cable to FTA 30 m
Number of processor modules 1...4
Total program and data memory for all user pro-
grams
10 MB less 4 kB for CRCs
Memory for retain variable
per user program 2 kB
A total for all user programs 32 kB
Number of variables
Example type INTEGER (16 bits):
Depending on the variable type
Number of simple variables 523 776
Number of retain variables 1 024
Number of system bus modules, per base plate 1...2
Maximum length of system busses 100 m
Using Fiber optic cables
(see Chapter
3.2)
19.6 km and more, if system bus la-
tency is configured
Number of communication modules 0...20
Count of safeethernet connections 0...255
Buffer of safeethernet
Connection to another HIMax controller. 1100 bytes
Connection to HIMatrix controller. 900 bytes
Connection buffer size to a X-OPC server. 128 kBytes
Number of user accounts 1...10
Number of user programs 1...32
Number of event definitions 0...20 000
Size of the non-volatile event buffer. 5000 Events
Parameter Value from ... to
Length of the names defined by the user
Username
Password
Project
Resource
Configuration
1...31 characters
Table 43: Dimensioning of a HIMax Controller
Detailed specifications are provided in the manuals for the individual components and in the
communication manual (HI 801 101 E).
