HIMA HIMax - The System Parameters of the Resource

5 Programming HIMax System
HI 801 001 E Rev. 4.01 Page 52 of 122
5.2.3.1 The System Parameters of the Resource
The system parameters of the resource can be set in SILworX, in the Properties dialog box
of the resource.
Parameter /
Switch
Description
Default
value
Setting for safe
operation
Name Name of the resource Any
System ID [SRS]
System ID of the resource
1...65 535
The value assigned to the system ID must differ to the
default value, otherwise the project cannot be exe-
cuted!
60 000
Unique value
within the con-
troller network.
This includes all
controllers that
may be poten-
tially connected
with one another.
Safety time [ms]
Safety time in milliseconds
20...22 500 ms
600 ms
Application-
specific
Watchdog time
[ms]
Watchdog time in milliseconds
6...7500 ms
200 ms
Application-
specific
ON:
The following switches/parameters can be
changed during operation (= RUN) using the
PADT:
 System ID
 Resource Watchdog Time
 Safety Time
 Target Cycle Time
 Target Cycle Time Mode
 Autostart
 Global Forcing Allowed
 Global Force Timeout Reaction
 Load Allowed
 Reload Allowed
 Start Allowed
OFF:
The parameters cannot be changed during
operation.
Main Enable
i
Main Enable can only be set to ON if the
PES is stopped, and cannot be set to ON
online!
ON
OFF is recom-
mended
ON:
If the processor module is connected to the
supply voltage, the user program starts
automatically
Autostart
OFF:
The user program does not start automati-
cally after connecting the supply voltage.
OFF
Application-
specific
ON: A cold start or warm start using the PADT is
permitted in the states RUN or STOP
Start Allowed
OFF: Start not allowed
ON
Application-
specific
ON: Download of the user program permitted Load Allowed
OFF: Download of the user program not permitted
ON
Application-
specific
ON: Reload of a user program permitted Reload Allowed
OFF:
Reload of a user program not permitted.
The reload process currently running is not
aborted when switching to OFF
ON
Application-
specific
ON: Global forcing permitted for this resource
Global Forcing Al-
lowed
OFF: Global forcing not permitted for this resource
ON
Application-
specific
