HIMA HIMax User Manual

HIMax System 5 Programming
HI 801 001 E Rev. 4.01 Page 57 of 122
5.2.3.3 Hardware System Variables for Reading the Parameters
These system variables can be accessed in the SILworX Hardware Editor. To this end,
select the dark-gray background outside the base plate symbols. Double-click or use the
context menu to open the detail view.
Variable Description Data type
Number of IO Errors Number of current I/O errors UDINT
IO Error Historic Count Counted number of I/O errors (counter resettable) UDINT
IO Warning Count Number of current I/O warnings UDINT
IO Warning Historic Count Counted number of I/O warnings (counter resettable) UDINT
Communication Error
Count
Number of current communication errors UDINT
Communication Error His-
toric Count
Counted number of communication errors (counter resettable) UDINT
Communication Warning
Count
Number of current communication warnings UDINT
Communication Warnings
Historic Count
Counted number of communication warnings (counter re-
settable)
UDINT
System Error Count Number of current system errors UDINT
System Error Historic
Count
Counted number of system errors (counter resettable) UDINT
System Warning Count Number of current system warnings UDINT
System Warning Historic
Count
Counted number of system warnings (counter resettable) UDINT
Autostart CPU Release
ON: When the processor module is connected to the supply
voltage, it automatically starts the user program
OFF: When the voltage supply is connected, the processor
module enter the STOP state
BOOL
OS Major [1] ... OS Major
[4]
UINT
OS Minor [1]...OS Minor [4]
Operating system version contained in processor module 1...4
UINT
CRC Project configuration checksum UDINT
Date/time [ms part] UDINT
Date/time [sec. part]
System date and time in s and ms since 1970-01-01
UDINT
ON: Forcing is deactivated. Force Deactivation
OFF: Forcing is possible.
BOOL
ON: Global or local forcing is active. Forcing Active
OFF: Global and local forcing are not active.
BOOL
State of the force switch
0xfffffffe No force switch set
Force Switch State
0xffffffff At least one force switch set
UDINT
ON: Global forcing is active. Global Forcing Started
OFF: Global forcing is not active.
BOOL
Spare 0 ... Spare 16 USINT
Spare in17
Reserved
BOOL
Last IO Warning [ms]
Date and time of the last I/O warning in s and ms since 1970-
UDINT
