3
────────────────────────────────────────────────────
1.2 Specifications
────────────────────────────────────────────────────
Dielectric strength
Between the case and the input
terminal
1.5 kVAC
Between the case and the powe
supply line
1.5 kVAC (sensitivity current: 5 mA)
Insulation resistance Between the case and the input terminal (for a minute)
Between the case and the power supply line (for a minute)
100 MΩ or more
External control
Open corrector output BCD 5 digit, measurement end, NG, comparator result
TTL input measuring range, comparator table, measurement trigger, print
zero adjustment, comparator output, temperature conversion
table
External interface The 9588 GP-IB INTERFACE (IEEE 488.2) (option)
Printer interface 9589 CENTRONICS (option)
Operating temperature/humidity 0℃ to 40℃ (32 Fto104F), 80% RH or less (no condensation)
Storage temperature/humidity -10℃ to 50℃ (14 Fto122F), 80% RH or less (no condensation)
Power supply and power
consumption
100, 110, 120, 200, 220, 240 VAC (±10%, 250 V MAX), 50/60 Hz,
maximum 40 VA
Dimensions and mass 215W×80H×320D mm (8.46"W×3.15"H×12.6"D) (excluding
protrusions), approx. 3.0 kg (105.8 oz.)
NOTE
･ The temperature correction function or the temperature conversion function is
selected when the unit is powered on, and only one of these functions can be
used at a time.
･ When using the temperature conversion function, the comparator uses its own
table (High/Low only).
･ Selection of the comparator table with the external interface constitutes a
temperature conversion table selection.
･ Auto ranging is always used when the temperature conversion function is
used.
