5.1 Setting the Comparator
────────────────────────────────────────────────────
5
.1.1 Setting the Comparator 1
SHIFT
COMP
SET
N
G
k
HIGH
LOW
Comparator table number Buzzer mode External control terminal mod
e
Comparison method
High limit value or standard valu
e
Low limit value or rang
e
NOTE
HIGH
LOW
Chapter
5
Applied Operation
s
5
.1 Setting the Comparator
(1) Press the SHIFT key and enter the shift states. "SHIFT" on the display lights.
(2) Press the
COMP key and enter the comparator table setting mode.
The comparator table which never has been set or been invalidated in Section
5.1.3, "Eliminating the Comparator Table" is displayed as shown below.
