.1.4 Remote State
NOTE
･ It is impossible to move to the GP-IB address setting mode without installing
the GP-IB interface unit as an option.
･ It is not possible to use the temperature correction function and the
temperature conversion function at the same time.
Under the key shift states, "SHIFT" on the display lights. When pressing any
key under this state, execute the function shown in the blue words under the
keys.
When pressing any key out of this state, execute the function shown in the
white words on the keys.
TEMP Executable functions out of the key shift state (white words).
0 ADJ Executable functions under the key shift state (blue words).
For example, pressing
TEMP key executes zero adjustment under the key shift
state, and selects the measurement mode out of the key shift state.
Pressing the
SHIFT key is able to select either the key shift state or the normal
state.
Under the key lock states, "LOCK" on the display lights and all key except are
invalid. To enter or release the key lock state, press the
LOCK key.
Under the remote states, "REMOTE" on the display lights and all key except
LOCK are invalid. When receiving any commands from GP-IB, enter this state.
In the each kind of setting mode, such as the comparator setting mode, when
receiving any commands from GP-IB, the 3227 returns to the primary
measurement mode automatically and enters the remote state.
To release the remote state, press
LOCK key, except receiving LLO (Local Lock
Out) command from GP-IB. When receiving this command, to release the
remote state, send GTL (Go To Local) command from GP-IB.
