Hioki 3227 - Valid Input Key Table

29
────────────────────────────────────────────────────
4.1 Operating Procedure
────────────────────────────────────────────────────
4
.1.5 Valid Input Key Table
● : Key input is valid.
−: Key input is invalid.
Keys
Out of the shift state In the shift state
Lock
state
Remote
state
Resistanc
e
Temper-
ature
Setting Resistanc
e
Temper-
ature
Setting
TEMP
0 ADJ
● ● − ● − − − −
COMP
SET
● − − ● *
4
● − − −
TC
SET
● − − ● *
4
● − − −
HOLD
SAMPL
● ● − ● − − − −
LOCK
50/60Hz
● ● ● ● ● − ● ●*3
SHIFT
● ● ● *
2
● ● ● *
2
− −
AUTO
● *
5
− ● *
6
− − − − −
UP
● − ● − − − − −
DOWN
● − ● − − − − −
● − ● *1 − − − − −
GP-IB ADRS
● − ● *1 ● ● − − −
ENTER
CLEAR
− − ● − − ● *
2
− −
*1: Invalid when setting the GP-IB address or the power supply frequency
*2: Valid only when setting the comparator tables or the temperature conversion tables
*3: Invalid under the LLO (Local Lock State) state
*4: Invalid under the holding state and when using the auto range (excluding when the temperature
conversion functino is selected)
*5: Invalid when using the comparator or displaying the temperature conversion
*6: Valid only when setting the temperature conversion tables
