3.4 Preparation for Measurements
────────────────────────────────────────────────────
3
.4.1 Resistance Measurements
Re
d
Blac
k
Re
d
Blac
k
SOURCE
SOURCE
SENSE
SENCE
SOURCE SENSE
SOURCE SENSE
Re
d
Blac
k
SOURCE
SENSE
SOURCE
SENSE
Red
Black
SOURCE
SENSE
SOURCE
SENSE
Shield
NOTE
3
.4 Preparation for Measurements
(1) When using the 9287 CLIP-TYPE LEAD (accessory)
Insert the lead to the input terminal of the front panel. Connect them with
putting the red ▼ mark of the 3227 upon the same mark of the red lead, and
the black ▼ mark upon the same mark of the black lead.
(2) When using the self-made leads
Connect them as follows.
When making the leads on your own work, be sure to shield to measure
accurately, and make the cable length within 5 m (the resistance of the wires
are 100 mΩ/m or less.)
