104
_____________________________________________________________________________________________
______________________________________________________________________________________________
SH1
All source handshake functions
AH1
All accepter handshake functions
T6
Basic talk functions
Serial poll function
Talk-only mode is not provided.
The talker cancellation function with MLA (My Listen Address) is
provided.
L4
Basic listener function
Listen-only mode is not provided.
The listener cancellation function with MTA (My Talk Address) is
provided.
SR1
All service request functions
RL1
All remote/local functions
PP0
Parallel polling is not provided.
DC1
All device clear functions
DT1
All device trigger functions
C0
The controller function is not provided.
(1) Connector
Use a 24-pin connector compatible with the IEEE-488 bus. Multiple standard
bus cables may be used.
(2) Interface function
