Hioki 3237 - Rear Panel

6
_____________________________________________________________________________________________
1.3 Names and Functions of Parts
______________________________________________________________________________________________
1.3.2 Rear Panel
3237
3238
3239
3237-01
3238-01
3239-01
Inlet
GP-IB interface
RS-232C interface
External I/O
Inlet
RS-232C interface
External I/O
Stand
Stande
Power/fuse ratings
Power/fuse ratings
Inlet
The power cord is connected here.
GP-IB interface
The GP-IB interface is connected here.
RS-232C interface
The RS-232C interface is connected here.
ExternalI/O
This is an external output terminal/external control terminal.
Power/fuse ratings
Indicates the power ratings and the fuse currently in use.
NOTE
Be sure not to bear down too hard on the top of the product when it is tilted
upwards. Doing so may damage the stand.
