Hioki 3237 - Chapter 7 RS-232 C Interface

49
_____________________________________________________________________________________________
______________________________________________________________________________________________
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Transmission mode Start-stop synchronization, full duplex
Transfer rate 9600 bps
Data length 8 bit
Parity None
Stop bit 1bit
Hand shake No X flow, hardware flow control
Delimiter CR, CR + LF for reception
CR + LF for transmission
Chapter 7
RS-232C Interface
RS-232C Interface enables all 3237/38/39 controls except 3237/38/39 power
switch.
RS-232C and GP-IB (-01) cannot be used simultaneously. Select either of
them. For information on performing the selection, refer to 7.1 Preparations
for Communication.
(1) Specifications
3237/38/39 RS-232C settings are configured as follows and cannot be
modified. Modify and adjust personal computer settings.
