2.2 Test Lead/Clamp Sensor Connection
______________________________________________________________________________________________
WARNING
The terminals do not have sufficient spatial isolation. To avoid
electrocution, observe the following precautions.
Connect test leads to the terminals only after shutting off the line
power.
Note that hazardous voltage may be present at the V
Ω
CLAMP terminal when using the A-terminal. Be careful to avoid
touching the V
Ω
CLAMP terminal and SENSE terminal.
Note that hazardous voltage may be present at the A-terminal when
using the V
Ω
CLAMP terminal and SENSE terminal. Be
careful to avoid touching the A-terminal.
When connecting the clamp-on sensor, should the metallic part of the
sensor, exposed while the clamp is open, touch the two wires of the
line, or if the sensor is used on a bare conductor, may result in a short
circuit or electrocution.
Although CAT III, CAT IV are stated on the L9170-10 TEST LEAD, the
DIGITAL HiTESTER is only compatible with CAT I and CAT II.
To avoid electrocution, do not measure the lines of CAT III or CAT IV.
CAUTION
To prevent an electric shock accident, confirm that the white or red portion
(insulation layer) inside the cable is not exposed. If a color inside the cable is
exposed, do not use the cable.
NOTE
Removable sleeves are attached to the metal pins at the ends of the test leads. The
test leads can also be used with the sleeves removed.
CAUTION
The tips of the metal pins are sharp, so take care not to injure yourself.
2.2 Test Lead/Clamp Sensor Connection
Removing and attaching the sleeves
Removing the sleeves
Gently hold the bottom of the sleeves and pull the sleeves off.
Safely store the removed sleeves so as not to lose them.
Attaching the sleeves
Insert the metal pins of the test leads into the holes of the sleeves, and firmly
push them all the way in.
