Hioki 3237 - Page 142

130
_____________________________________________________________________________________________
10.2 Accuracy
______________________________________________________________________________________________
Range
Maximum
display
Measurement
current
Open-circuit
voltage
Overload
protection
200 Ω 199.999 Ω 1mA 5%
6Vmax. 500 Vpk
2000 Ω 1999.99 Ω 1mA 5%
20 kΩ 19.9999 kΩ 100 uA 5%
200 kΩ 199.999 kΩ 10 uA 5%
2000 kΩ 1999.99 kΩ 1uA 5%
20 MΩ 19.9999 MΩ 100 nA 5%
100 MΩ 100.000 MΩ 20 nA 5%
Range SLOW MEDIUM FAST
Temperature
coefficient
200 Ω 0.05 , 8 0.05 , 18 0.05 , 300 0.005 , 0.8
2000 Ω 0.05 , 2 0.05 , 12 0.05 , 100 0.005 , 0.2
20 kΩ 0.05 , 2 0.05 , 12 0.05 , 100 0.005 , 0.2
200 kΩ 0.05 , 2 0.05 , 12 0.05 , 200 0.005 , 0.2
2000 kΩ 0.05 , 2 0.05 , 12 0.05 , 200 0.005 , 0.2
20 MΩ 0.3 , 4 0.3 , 20 0.3 , 200 0.03 , 0.4
100 MΩ 3,10 3,50 3 , 500 0.3 , 1
Range
Maximum
display
Measurement
current
Open-circuit
voltage
Overload
protection
2000 Ω 1999.99 Ω 100 uA 5%
0.45Vmax. 500 Vpk
20 kΩ 19.9999 kΩ 10 uA 5%
200 kΩ 199.999 kΩ 1uA 5%
2000 kΩ 1999.99 kΩ 100 nA 5%
Range SLOW MEDIUM FAST
Temperature
coefficient
2000 Ω 0.05 , 6 0.05 , 14 0.05 , 300 0.005 , 0.6
20 kΩ 0.05 , 6 0.05 , 14 0.05 , 300 0.005 , 0.6
200 kΩ 0.05 , 6 0.05 , 14 0.05 , 300 0.005 , 0.6
2000 kΩ 0.3 , 6 0.3 , 20 0.3 , 500 0.03 , 0.6
Resistance Measurement Function
(1) Range
(2) Accuracy % rdg. dgt. (After performing zero ajust)
Low-power Resistance Function
(1) Range
(2) Accuracy % rdg. dgt. (After performing zero ajust)
